Descripción
Información de Producto
CERRADURA ELECTROMAGNÉTICA DE 600 LB, PUERTA DOBLE, SENSOR DE ADHERENCIA, LED DE ESTADO, LISTADO UL
Modelo: E941DA600PQ
Marca: ENFORCER SECOLARM
Especificaciones:
- 600-lb (272kg) Holding force per door
- No residual magnetism
- MOV Surge protection
- Built-in status LED shows locked/unlocked status
- Built-in bond sensors with 3A@12VDC dry relay output for monitoring door status
- Anodized aluminum housing (US 28)
- Adjustable mounting bracket
- Complete mounting hardware for typical installations
- Additional brackets available for easy mounting or atypical situations
- Detachable faceplate for easy access to wiring
- 12/24VDC Selectable
- Multiple UL listings
-
-
- UL294 Access Control System Units – USA
- UL10C Positive Pressure Fire Test – USA
- UL10B Fire Test of Door Assemblies – USA
- ULC-S104 Fire Test of Door Assemblies – Canada
-
-
| Holding force | 600-lb (272kg) per door |
| Operating voltage | 12 /24 VDC (selectable) |
| Current draw | 500mA@12VDC per door (1A total) 270mA@24VDC per door (540mA total) |
| Bond sensor relay | Yes |
| Status LED | Yes |
| Operating temperature | 32º~120º F (0º~49º C) |
| Electromagnet dimensions | 19-11/16″ x 1-5/8″ x 1-1/16″ (500x40x26 mm) |
| Armature dimensions | 7-1/4″x1-1/2″x1/2″(185x38x12 mm) |
| Weight | 9-lb (4kg) |
| Destructive attack | Level I |
| Line security | Level I |
| Standby power | Level I |
| Endurance | Level IV |
